High Precision Beveling Edging Processing Machine For Glass
|Size of whole machine(mm)||7800X1400X2500mm|
|No.1||Diamond wheel||Rough beveling|
|No.2||Diamond wheel||Rough beveling|
|No.3||Diamond wheel||Bottom grinding|
|No.4||Resin wheel||Fine beveling|
|No.5||Resin wheel||Fine beveling|
|No.6||Resin wheel||Fine beveling|
|No.7||Wool wheel||Bevel polishing|
|No.8||Wool wheel||Bevel polishing|
|No.9||Wool wheel||Bevel polishing|
1. XM351 is designed for grinding and polishing a bevel edge, with bottom edge of glass with different size and thickness.
2. Rough grinding, fine grinding, polishing of bevel and grinding of bottom edge can be completed in one time.
3. The processing speed is adjustable with stepless motor.
4. Input and output conveyor adopt timing belt which can improve the transmission precision.
5. It is easy to operate and has good performance.
6. The wheels and motor adopt direct transmission;
7.The machine with lubricating system
8. This machine had two options, one is digital display. There are four meters; they will display processing speed, glass thickness, glass bevel angle, surplus thickness. And the other one is Schneider PLC Control with touch screen.
